Light-Duty EV Rear Axles & Transaxles
JY Powertrain manufactures elite, robust rear transaxles specifically optimized for low-speed vehicles, AGVs, and hunting buggies. Built with integrated high-grade helical gearboxes, precision differentials, and premium drum braking systems, they ensure maximum battery efficiency and whisper-quiet power delivery.
- Integrated Structure: Unified motor flange, gearbox, and axle housing to minimize drivetrain loss.
- Premium Drum Brake: Equipped with optional Ø160mm or Ø220mm high-performance hydraulic drum brakes.
- Whisper Quiet Gears: Helical gears processed via CNC tooth grinding to maintain noise levels under 65 dB.
GM162 Integrated Transaxle System
Light-Duty Series Specs
| Model Series | Rated Load | Max Motor Input | Available Gear Ratios | Brake / Housing Pipe | Primary Application |
|---|---|---|---|---|---|
| GM136 Series (Semi-Floating) |
≤ 0.65 T | ≤ 4.0 KW | 10.26 / 12.76 | Ø160/180mm Drum φ60/φ65 Pipe |
Standard Golf Carts, Lightweight AGVs, Smart LSVs |
| GM162 Series (Semi / Full-Floating) |
1.0 - 1.4 T | ≤ 7.5 - 9.0 KW | 6.47 / 10.27 / 12.49 14.67 / 18.12 |
Ø220mm Drum φ65/φ70 Pipe |
Scenic Sightseeing Buses, Patrol Cars, Cargo LSVs |
Heavy-Duty EV Rear Axles & Transaxles
For heavy city-logistics transport, large sightseeing fleets, airport GSE tugs, and agricultural vehicles. Engineered to handle high peak input power and punishing load environments under the rigorous IATF 16949:2016 automotive standard.
Tested and certified by the China Merchants Testing Vehicle Technology Research Institute (Report No. QE25WT1G52901) under standard QC/T 533-2020:
- Static Torsional Reserve Factor: Reached 3.55 (Standard requirement is only >1.8).
- Gear Fatigue Life: Completed 300,000+ cycles under full load with zero structural defect.
- Full-Floating Setup: Hub bearings handle all weight load, shielding half-shafts entirely from bending stress.
- Heavy-Duty Braking: Optional Ø240mm/Ø250mm robust drum brakes to guarantee reliable stop times.
GM218 Heavy-Duty Drive Axle Assembly
Heavy-Duty Series Specs
| Model Series | Rated Load | Max Motor Input | Available Gear Ratios | Brake / Housing Pipe | Primary Application |
|---|---|---|---|---|---|
| GM192 Series (Semi / Full-Floating) |
1.5 - 1.8 T | ≤ 30.0 KW | 7.5 / 8.5 / 9.0 10.5 / 17.8 |
Ø240/250mm Drum φ70/φ76 Pipe |
Heavy-Duty Cargo LSVs, Electric Airport Tug Tractors |
| GM218 / 212 Series (Full-Floating HD) |
≤ 2.5 T | ≤ 40.0 KW | 13.65 / 18.12 (5.375 for 212) |
Ø220/250mm Drum φ76/φ80 Pipe |
City Logistics Trucks, Scenic Shuttle Fleets, Engineering LSVs |
